Harbin Pioneer M&E technical development Co., Ltd. can provide you with a tool setting system for your turning centers to help you achieve efficient and high-precision machining. The fully automatic tool setting system can automatically complete the setting of all tool parameters without operator intervention. You can choose or customize tool setting arms of different specifications according to the size of the machine tool. The sturdy and durable tool setting arm can ensure long-term operation in harsh machining environments, and the dedicated tool setting probe has high repeatability and positioning accuracy, ensuring the overall stable and efficient operation of the system.

Basic components of the tool setting system

• Automatic swing arm LTA (including connecting cables)

• Tool setting probe TP3

• Interface  APT-6 (including connecting cables)；

• Tool setting probe storage box

• Tool setting software package

Application of tool setting system

• Provides a platform for multiple applications for tool setting, tool breakage detection and workpiece detection;

• Releases the processing potential of machine tools, realizes large-scale unmanned production, and ensures the consistency and reliability of processing

Notes on purchase

If you purchase our LTS-10 tool setting system, which includes the basic configuration of tool setting probe, control box, automatic swing arm and tool setting software (see details page), please consult our sales staff whether the CNC system used by the machine tool to be installed can be equipped with the LTS-10 tool setting system. Some CNC systems require additional settings to use this product;

If you want to change the configuration, please pay attention to the following tips:

• Regarding the installation dimensions of the tool setting system, please verify the chuck size and tool size of your machine tool before ordering this product, and select the appropriate product according to the order form provided by our company;




• Regarding the stylus of the TP3 tool setting probe, please purchase according to the stylus size corresponding to the tool square specification. For details, please consult our staff;




• Regarding the cable length, verify whether the length of the connecting cable between the automatic swing arm LTA and the interface can meet the installation requirements; the cable is optional 3m/5m/10m, please specify when ordering this product.
